Insulation Resistance Monitoring Relay for AC Networks RCSI-1002

Insulation Resistance Monitoring Relay for AC Networks RCSI-1002 — VIBRATOR OJSC

Brand: null

$90 - $300 USD

MOQ: 20 pieces

Key Features

Insulation resistance monitoring range, kOhm: 50-500

Overall dimensions, mm: 70.5 x 100 x 102 mm

Operating temperature: -10...55 °C

Switched current: 5 A

Supplier Information

VIBRATOR OJSC

🇷🇺 📦 🏭 🛡️

View All Products (51)

Quick Inquiry

Description

RKSI-1002 is designed to monitor the insulation resistance in AC networks under voltage, and to issue a signal on the reduction of insulation resistance below a predetermined threshold. The voltage of the controlled network RKSI-1002 - 127, 220, or 380 V (from minus 30% to plus 20% AC).

The devices are made in a housing for installation on a DIN-rail.

Specifications

Insulation resistance monitoring range, kOhm

50-500

Overall dimensions, mm

70.5 x 100 x 102 mm

Operating temperature

-10...55 °C

Switched current

5 A

Output signal type

dry contact for switching

Power consumption

6

Time to establish operating mode

3

Degree of protection

IP20

Number of channels

1 pcs

Provides explosion protection of the type

no

Explosion protection type marking

none

Rated fuse melting current, mA

1000

Power supply voltage

380 V

weight

0.6 kg

dimensions

70.5...100

Operating voltage

380 V

maximum operating current (max.

0.05 A
