Reverse Plow PPO-9 (8+1) for Soil Tillage

Reverse Plow PPO-9 (8+1) for Soil Tillage — GKZ PJSC

Name: Reverse Plow PPO-9 (8+1) for Soil Tillage
Brand: null
SKU: 156943
Availability: InStock

Brand: null

$3,600 - $9,600 USD

MOQ: 1 pieces

Key Features

performance: 2...4

Housing working width: SBVVBG cm

Supplier Information

GKZ PJSC

🇷🇺 📦 🏭 🛡️

View All Products (55)

Quick Inquiry

Description

The PPO-9 (8+1) is a nine-body semi-mounted reversible plow manufactured by GKZ PJSC — Gryazinsky Cultivator Plant (Грязинский культиваторный завод), a Russian enterprise with over 60 years of specialization in tillage equipment. The plow is designed for general-purpose ploughing of various soil types to prepare ground for grain and industrial crops, working at depths between 15 and 30 cm.

Its reversible mechanism carries nine left-turning and nine right-turning bodies, each with a 50 cm working width, delivering a total working width of 2.97–4.5 m and a field capacity of up to 4 ha/h. The robust main beam is fabricated from seamless square tube (160×160×10 mm), and all bodies are protected from hidden obstructions by a sacrificial shear bolt.

The plow can operate both in-furrow and out-of-furrow, and accepts optional equipment including a soil consolidator, presowing disc coulters, and foreheads (predpluzhniks) for burying crop residue. Body moldboards are available in wing or full-surface profiles, and double support wheels can be fitted.

Transport speed reaches 15 km/h with a ground clearance of at least 350 mm, and dry machine weight is 4094 ± 123 kg.

Details & Equipment

PPO-9 Plow Gallery

Side View — Working Configuration

The PPO-9 (8+1) shown in working position with all nine bodies deployed; the seamless square-tube main beam and semi-mounted rear wheel assembly are clearly visible.

Body and Moldboard Assembly

Close view of the plow body set with full-surface moldboards; each body is protected by a shear bolt and mounted on the reinforced beam at 1000 mm intervals.

Reversing Mechanism

The hydraulic reversing mechanism swings all bodies from left-turning to right-turning, enabling headland turns without creating a dead furrow.

Field Operation

The PPO-9 at work in the field; with a 50 cm body width the nine-body configuration delivers a 4.5 m working width and throughput of up to 4 ha per hour.

Features

🔄

Reversible Design

Nine left-turning and nine right-turning bodies allow headland-free ploughing without dead furrows, suitable for fields of any shape.

📐

Heavy-Duty Beam

The load-bearing frame is welded from seamless square tube 160×160×10 mm, providing high rigidity under heavy draught loads.

⚙️

Shear-Bolt Protection

Each body is secured by a shear bolt that sacrificially breaks on hidden stone strikes, protecting the entire share assembly from damage.

🌾

Flexible Body Width

Bodies are available in 33, 38, 44, or 50 cm working widths, letting operators match tillage width and tractor class to field conditions.

🚜

Semi-Mounted Coupling

Semi-mounted attachment distributes weight between tractor and plow's own rear wheel, maintaining stability over long working widths up to 4.5 m.

🔩

Reinforced Wheel Bracket

The support wheel bracket is reinforced with gusset plates, and a double wheel option is available for work on soft or wet soils.

Buyer Benefits

No dead furrows — reversible bodies leave a level surface after each pass, reducing additional levelling work
Wide working width of 2.97–4.5 m cuts time per hectare, achieving up to 4 ha/h on suitable soils
Tills to a depth of 15–30 cm in a single pass, meeting agrotechnical requirements for both shallow and deep ploughing
Modular configuration (8 or 9 bodies) via an aggregation kit allows the plow to match different tractor power classes
Optional fordplowshares (predpluzhniks) ensure reliable incorporation of crop residues and weed cover
Transport speed of up to 15 km/h and 350 mm ground clearance enable safe and fast road travel between fields
Manufactured at GKZ PJSC, a specialist Russian tillage-equipment plant with more than 60 years of production experience

Applications

Ploughing virgin and reclaimed soils under grain crops (wheat, barley, rye) Autumn primary tillage for winter crops on high-yield arable land Spring deep ploughing in preparation for sunflower, sugar beet, and other row crops Incorporation of post-harvest stubble and green manure crops Breaking up compacted subsoil layers on intensively farmed fields Large-scale farm operations where high daily output and minimal overlap are critical Work on irregularly shaped or narrow fields where dead-furrow-free tillage is preferred Farms pairing the plow with a soil consolidator to combine tillage and seedbed preparation

Source: official manufacturer website
