Name: Explosion-Proof Three-Phase Induction Motors, Rotor Height 250-280mm, < 75kW
Brand: RUSELPROM-VEMZ
SKU: 255815
Availability: InStock

Brand: RUSELPROM-VEMZ

$450 - $1,800 USD

MOQ: 5 pieces

Key Features

Output shaft speed: 600...3000

Rated operating voltage: 220 V

Rotational speed: 750...3000

Frequency of supply voltage: 50...60

Supplier Information

RUSELPROM-VEMZ LLC

🇷🇺 📦 🏭 🛡️

View All Products (11)

Quick Inquiry

Description

The ВА 250–280 series from RUSELPROM-VEMZ are explosion-proof, squirrel-cage induction motors purpose-built for hazardous industrial environments. Manufactured at the Volzhsky Electromechanical Plant (ВЭМЗ) — part of the Ruselprom concern, Russia's foremost electric machine developer — these three-phase asynchronous motors carry the 1ExdIIBT4 explosion-protection certification, qualifying them for all classes of explosive gas, vapor, and dust atmospheres in chemical, oil-and-gas, and refining plants.

Frame sizes 250 and 280 mm deliver synchronous speeds of 750, 1000, 1500, and 3000 rpm at power ratings up to 75 kW, with dual voltage ratings of 220/380 V and 380/660 V supporting both 50 Hz and 60 Hz supply systems. Enclosures achieve IP54 ingress protection as standard (IP55 available on request), and Class F insulation ensures continuous S1-duty reliability across an extensive range of Russian and tropical climatic codes, from Arctic-grade УХЛ1 to tropical Т2 and Т2.5.

Multiple mounting configurations — IM1001, IM2001, and IM3011 as standard, with further options available — make integration into existing plant layouts straightforward. The squirrel-cage rotor requires no brush gear, minimising maintenance in remote or hazardous locations.

Details & Equipment

Motor Design

ВА Series Overview

The ВА series explosion-proof motors feature a robust cast frame with integrated cooling fins, IP54 sealed terminal box, and grounding provisions — purpose-designed for continuous-duty operation in hazardous chemical and oil-and-gas facilities.

ВА250 Frame Motor

A 250 mm shaft-height ВА motor showing the standard IM1001 foot-mount configuration, dual-voltage terminal box rated 220/380 V or 380/660 V, and explosion-proof enclosure marked 1ExdIIBT4 — suitable for direct-on-line or variable-frequency-drive operation.

Features

🔥

Explosion-Proof Certified

Certified 1ExdIIBT4 under GOST R 51330 for gas/vapor groups IIA and IIB; suitable for all hazardous-zone classes in chemical, oil, and gas facilities.

⚡

Wide Voltage & Frequency Range

Dual winding connections accommodate 220/380 V and 380/660 V networks; both 50 Hz and 60 Hz supply frequencies are supported for domestic and export projects.

🌡️

All-Climate Execution

Available in climatic versions У1, У2, У3, У2.5, УХЛ1, УХЛ2, УХЛ2.5, Т2, and Т2.5 — covering sub-Arctic outdoor to tropical indoor applications.

🛡️

IP54 Ingress Protection

Standard IP54 enclosure (IP55 optional) with IC0141/IC411 surface cooling ensures reliable performance in dusty, wet, and chemically aggressive environments.

🔩

Versatile Mounting

IM1001 (B3 foot), IM2001 (B5 flange), and IM3011 (B35 combined) are standard; additional configurations available on request to simplify retrofit installations.

♾️

Continuous Duty S1

Class F insulation rated for S1 continuous operation; direct-on-line starting standard with optional VFD compatibility enabling speed-regulated drives.

Buyer Benefits

Certified 1ExdIIBT4 explosion protection — compliant with TR TC 012/2011 for deployment in Zone 1 and Zone 2 hazardous areas without additional protective measures
Both 50 Hz and 60 Hz supply compatibility reduces stock duplication for exporters and equipment integrators working across multiple countries
Nine climatic execution variants — from Arctic УХЛ1 to tropical Т2.5 — cover every installation geography in a single motor family
IP54 as standard protects windings and bearings against dust and water ingress in outdoor or process-area installations
Squirrel-cage rotor eliminates brush and slip-ring maintenance, reducing lifecycle service costs in hard-to-access or hazardous locations
Multiple standard mounting configurations (foot, flange, combined) simplify integration with existing pump, fan, and drive-train interfaces
Manufactured by RUSELPROM-VEMZ at the dedicated ВЭМЗ facility — Russia's leading explosion-proof motor specialist with decades of certified production experience

Applications

Centrifugal and screw pump drives in oil refineries, chemical plants, and gas processing facilities Compressor drives in natural gas storage and pipeline booster stations Fan and ventilation drives in chemical production buildings and underground mines Conveyor and elevator drives in petrochemical and explosive-dust-producing industries Mixer and agitator drives in paint, lacquer, and solvent manufacturing Machinery drives in Zone 1 and Zone 2 classified areas where gas/vapor IIA–IIB mixtures may form General-purpose mechanical drives in oil-and-gas offshore and onshore installations Export equipment packages requiring 60 Hz operation for international EPC projects
