Description

GOST LLC (Zavod Kranov) designs and manufactures electric gantry cranes covering lifting capacities from 1 to 400 tonnes — bridge-type hoisting machines built to move heavy and oversized loads across open yards, construction sites, industrial facilities, and shipbuilding berths. Available in single-beam and double-beam configurations, the cranes are grouped into three performance tiers: general-purpose models up to 32 tonnes for enterprises and open-air warehouses, construction-and-installation variants up to 80 tonnes for building erection and in-shop equipment rigging, and special-purpose cranes up to 130 tonnes and beyond for transportation hubs and major industrial complexes.

Working mode classification spans A1 through A11 per GOST 34017-2016, and three control methods are offered — floor pendant, stationary or travelling cab, and radio remote. Climate execution covers Moderate, Moderate-Cold, Cold, and Tropical grades for outdoor and indoor deployment; hazardous-area options include fire-safe and explosion-proof execution.

GOST LLC provides the complete service chain: in-house engineering and design, fabrication, delivery across all of Russia, site installation, and ongoing maintenance backed by a 24-month factory warranty, with technical faults resolved within one working day.

Details & Equipment

Electric Gantry Crane Gallery

Heavy-Duty Gantry Crane

A GOST-manufactured electric gantry crane shown in field installation, demonstrating the robust double-beam bridge structure suited to high-capacity industrial lifting tasks.

Open-Yard Installation

Electric gantry crane deployed on an outdoor rail track, illustrating the crane's suitability for open construction and storage yards with full electric drive.

Gantry Crane on Site

Crane in active service at an industrial facility, showcasing GOST LLC's complete installation capability from portal frame assembly to commissioning.

Bridge Structure Detail

Close view of the crane bridge and running gear, highlighting the rigid portal frame and end-beam trolley arrangement used across the full capacity range.

Construction-Site Crane

Construction-and-installation configuration electric gantry crane at a large civil project, demonstrating the product line's role in building erection and equipment rigging.

Crane Model Overview

Product overview view of a GOST electric gantry crane, illustrating the configurable cantilever extensions and cargo trolley arrangement available to order.

Features

🏋️

Lifting Capacity

Rated capacity spans 1 to 400 tonnes in single- or double-beam configuration, addressing everything from light workshop handling to the heaviest industrial lifts.

⚙️

Duty Classification A1–A11

Working mode is specified per GOST 34017-2016 across the full A1–A11 range, ensuring the drive train is matched precisely to the application's operating cycle.

🎮

Flexible Control

Three control options — floor-level pendant, stationary or travelling operator cab, and radio remote control — cover all safety and productivity requirements.

🌡️

Climate & Environment Variants

Supplied in Moderate (U), Moderate-Cold (UHL), Cold (HL), and Tropical (T) climatic versions, plus general-industrial, fire-safe, and explosion-proof execution types.

🔧

Configurable Structure

Bridge with or without cantilever extensions, end-beam running trolleys, and a choice of cargo trolley or electric hoist allow the crane layout to suit any site geometry.

🏭

Full-Cycle Production

GOST LLC handles design, fabrication, delivery, installation, and maintenance in-house, backed by a 24-month factory warranty and one-working-day fault resolution.

Buyer Benefits

Wide capacity range from 1 to 400 tonnes lets one supplier cover all project phases, from light assembly to heavy construction erection.
24-month factory warranty combined with same-working-day fault response minimises unplanned downtime and keeps production schedules on track.
Turnkey service — from engineering design through commissioning — eliminates coordination risk between separate design, fabrication, and installation contractors.
Radio remote control option improves operator safety on busy open-yard sites where floor-level operation is impractical.
Explosion-proof (VBI) and fire-safe (PBI) execution variants qualify the crane for petrochemical, gas, and mining environments.
A1–A11 duty classification prevents both over-specification and undersizing, reducing capital cost and extending service life.
Direct-from-manufacturer supply with delivery across Russia removes dealer mark-ups and shortens the logistics chain.

Applications

Open-air construction yards for erection of large civil and industrial structures Shipbuilding slipways and dry docks for hull block positioning and module handling Outdoor materials-storage warehouses and bulk cargo terminals Engineering and manufacturing workshops for heavy equipment assembly and in-shop rigging Transportation hubs for intermodal cargo loading and transfer operations Petrochemical and gas facilities requiring explosion-proof crane execution Steel service centres for coil, plate, and structural section handling Power-plant construction sites for lifting generator sets, transformers, and structural modules
