The VEC-237-USB-UVC is a professional-grade 2-megapixel color TV camera with a USB 2.0 interface, designed and manufactured by EVS LLC (ООО "ЭВС"), a St. Petersburg-based developer recognized as Russia's leading TV camera producer.
EVS conducts its entire production cycle in-house — from R&D and PCB fabrication to final assembly and acceptance testing — and exports cameras to Western Europe and the United States.
Built around a Sony IMX-290 backside-illuminated (BSI) CMOS sensor in 1/2.8-inch format, the VEC-237-USB-UVC delivers 1920×1080 pixels at a 2.9×2.9 µm pixel pitch with up to 1,000 TV lines of resolution. Minimum sensitivity reaches 0.004 lux at f/1.2 aperture and 30 fps; extended-exposure mode (1.5 seconds) pushes sensitivity to just 0.00015 lux for low-light scientific and industrial tasks.
The full dynamic range spans 0.004 to 50,000 lux.
The camera outputs uncompressed YUV422 or compressed MJPEG video over USB 2.0 — achieving Full HD 30 fps in MJPEG mode — and is plug-and-play compatible with Windows XP SP3 through 10, Linux, Android 7+, and iOS via the built-in UVC driver. No additional driver installation is needed.
Power is drawn entirely from the USB port at no more than 150 mA. The compact 50×58×30 mm module accepts standard CS-mount lenses with focal lengths from 2 to 50 mm.
Operating temperature spans −60 °C to +80 °C. Two-year warranty.
