Microammeter, milliammeter, ammeter and voltmeter panel-mounted: version M42303.

Panel Analog Measuring Instruments

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Devices M42303 are designed to measure current and voltage in DC electric circuits. Devices with upper values of measuring ranges 0,5 mA, 20 V and all multipredelnye are made only accuracy class 4,0. DC instruments can be manufactured: with zero mark at the edge or inside the measuring range; with other measuring ranges and with scales calibrated in units of any physical quantities, with special marks, inscriptions, etc. according to the customer's data. The normal position of the instruments is vertical or horizontal. It is possible to produce instruments of normal position at an angle to the horizon. The design of enclosures provides protection degree IP50 or IP54 for the front panel, IP00 for live parts. Verification of the devices is performed in accordance with the requirements of GOST 8.497-83. The dials and scales of the devices are made in accordance with GOST 5365-83. M42303 are included in the State Register of measuring instruments of the Russian Federation No. 68770-17. Interverification interval - 2 years.

Technical Specifications

Dimensions of the front panel, mm	40?40
Panel cutout, mm	Ø37,5
Scale length, mm, not less	26
Accuracy class	2,5; 4,0
Degree of protection IP	Dust and splashproof IP54 (for M42303 devices with "Sea Register" acceptance - IP54)
Weight, kg, not more	0,08
Current measuring range (direct connection)	µA (100; 200; 300; 500; 1000); mA (0.5; 1; 2.5-0-2.5; 5; 10; 10; 15; 20; 30; 50; 100; 150; 300; 500; 600; 30/600); mA (50 mA/20 V); A (1; 2; 3; 5; 10)
Current measurement range (connection with 75 mV external shunt and a pair of 0.035 ohm calibrated wires)	A (20; 30; 50; 75; 100; 150; 200; 300; 500; 750; 200-0-750); kA (1; 1.5; 2; 4; 6)
Voltage measuring range (direct connection)	? - 2; 3; 7,5; 10; 15; 20; 30; 50; 75; 100; 150; 250; 300; 500; 600; 0,075/9; 2,5/10; 3/100; 3/300; 10/300; 30/300; 6; 25; 400
Voltage measuring range (connection with external additive resistor with nominal current 5 mA)	kV - 1; 1,5; 3

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
