Available for Import
R50 Type Switch 1/9 for 1435 mm Gauge Railways - Ideal for Track Construction
Manufacturer:
MSZ OJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
The R50 type 1/9 wooden bar type R50 track switch is designed for laying on railway tracks of 1435 mm gauge. The arrow has a reinforced design of the root unit. The crossbar is monobloc with welded rails. The counter rail is not connected to the track rail. All pads have high flanges. The shackles are HFI hardened.
Specifications
View in the direction of a side or crossing track
Right
Arrow design
With rotating sharps
Cross brand
1/9
View
Single
Rail type
?50
Type of under-rail base beam for laying connections
wooden
Type of product according to PP RF 616
Broad gauge switches
