Available for Import

Vertical milling machine 6820F1

Metal Milling Machines

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

-Vertical milling machine 6820F1 is a universal machine and is suitable for most tasks related to the processing of small-sized parts made of steel, cast iron, aluminium.
-High rigidity of the machine, the presence of a rotary head and high torque expand the technological capabilities of the machine, allowing a more flexible approach to the fulfilment of tasks
-Vertical milling machine with a rotary head is designed to perform all kinds of milling work on parts made of ferrous and non-ferrous metals in single, small batch, serial production.
-Rigid one-piece cast housing parts of the machine: bed, column and table carriage are made of high quality cast iron and guarantee long-term serviceability and stability of geometric accuracy of the equipment.
-The feed box allows to control three axes of the machine using only one motor.
-The machine is equipped with a counterweight to reduce the load on the vertical feed ball screw.

Specifications

Type of product according to PP RF 616 Vertical milling machines

Length 4660 mm

Width 2600 mm

Height 2700 mm

Length of machined surface 1400 mm

Working width 600 mm

Weight 7000 kg

Maximum spindle speed 1800

Maximum torque 1814 Nm

Number of speeds B1/B8 2100/900 MHz pc

Main engine power 7.6 kW

Spindle cone ISO50

Tool clamp Hydraulic

Range of head rotation angle relative to the slide +90 ... -90 deg.

Range of head half-shell rotation angle 0 ... +180 deg.

Diameter of screw for X, Y, Z axes 40 mm

Screw pitch for X, Y, Z axes 10 mm

Ball screw class for X, Y, Z axes C3 mm

Z-axis travel (Vertical spindle movement) 650 mm

Working feed rate in X, Y axes (Transverse table movement) 2000 mm/min

Working feed rate in Z axis (Longitudinal table movement) 1000 mm/min

Accelerated feed rate in X, Y axis (Transverse table movement) 5000 mm/min

Accelerated feed rate in Z axis (Longitudinal table movement) 2500 mm/min

Table length 2000 mm

Table width 530 mm

Maximum permissible table load 2000 kg

T-slots (width x number x distance) 20x5x80 mm

Discreteness of axis mapping 0.01 mm

Minimum travelling distance of an axis 0.01 mm

Lubrication system pump power 42 W

Oil consumption 200 cm3/min

Tank capacity 3 l

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.

Share your requirements for a quick response!

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
