Magnetic powder flaw detector MAGNITEST-U 2000

Magnetic Flaw Detectors

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Magnetic powder flaw detector MAGNITEST-U 1000 Magnetic powder flaw detector MAGNITEST-U 2500 Magnetic powder flaw detector MAGNITEST-U 1500

Description

Magnitepowder flaw detector MAGNITEST-U 2000 provides detection of longitudinal and transverse defects with minimum dimensions (in accordance with GOST R 56512-2015): opening 0,0001 mm, depth 0,01 mm, length 0,5 mm, as well as larger ones.
In accordance with GOST 21105-87 sensitivity classes "A", "B", "C" are provided.
Advantages:
- automation of control operations;
- design of contact plates excluding "burns";
- input of currents up to 12 kA during part rotation;
- library of parameters of product control;
- simultaneous magnetisation and inspection of the clamped part;
- automatic maintenance of the circular magnetising current value;
- parameter setting and display on a touch screen with intuitive interface;
- smooth adjustment of the magnetising currents;
- magnetising current measurement system RSI;
- slurry splash protection system;
- white light or ultraviolet illumination;
- placement of a blackout system on the installation, if necessary.

Specifications

Type of product according to PP RF 616 Instruments and other instruments for measurement, control and testing

Maximum size of the controlled object, length 2000 mm

Maximum size of the controlled object, diameter 400...700 mm

Type of magnetizing current AC, DC

Maximum distance between contact plates 2000 mm

Amplitude of circular magnetizing current 100...12000 A

Current maintenance accuracy 10 %

Value of longitudinal magnetic field strength between headstocks separated by 500 mm, A/cm, not less than 100

Value of longitudinal magnetic field strength in the centre of the contact plate, A/cm. at least 500

Maximum value of longitudinal magnetic field strength at the centre of the longitudinal magnetising solenoid, A/cm 400

Illumination of the control object surface with white light, not less than 1000

Maximum weight of the controlled object 100 kg

Intensity from UV source on the carriage, µW/cm2 2000

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
