Airspace Control System (SKVP) for Monitoring Airspace Usage

Radar Equipment

Manufacturer: CKBA OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Airspace control system is designed to provide control over the regime of airspace use (including unmanned aircraft and small aviation) and continuous control of airspace over the designated area.Viewing area: in azimuth - +-45 degrees, in angle of place -5 ... +45 degrees. Detection range: - for small aircraft, not less than 30 km; - for medium UAVs such as "Orlan-10", not less than 18 km; - for mini UAVs such as "DJI Inspire 2", not less than 7 km; - for micro UAVs such as "DJI Mavic" (DJI Phantom), not less than 4 km. The range of radial velocities of detectable targets is 10/270 m/s.

Specifications

Weight

115 kg

Power consumption 230 V, 50 Hz

750 W

Range resolution

30 m

Maximum number of simultaneously escorted targets

20 pcs

Type of power amplifier

solid-state

Antenna unfolding

1...1.2 m

Antenna type

Fixed FAR

Operating frequency range

S-band
