AIR FILTERING UNIT FOR SAMPLING AEROSOLS FROM ATMOSPHERIC AIR "RAB-01"
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Description
Air-filtering installation for sampling of aerosols from atmospheric air Automatic installation for atmospheric air radioactivity control "VFU" (hereinafter referred to as "VFU") according to TU 26.30.60-1044-23151859-19 is designed to measure the flow rate and volume of air pumped through the filtering fabric. The unit allows to accumulate anthropogenic and natural radionuclides from atmospheric air aerosols, and further, accordingly, to estimate volumetric activity of radionuclides in atmospheric air.
The gamma-quantum detection unit (GD) included in the HFC is designed for preliminary estimation of gamma-quantum flux near the filter of aerosol activity accumulated on the filter fabric.
It is recommended to use the HFC in the zone of possible scattering of gas-aerosol releases of radionuclides from the radiation facility.
The air-filtering unit carries out:
-continuous sampling of aerosols from atmospheric air onto the filter fabric;
-measurement of volumetric flow rate of air, pumping...
The gamma-quantum detection unit (GD) included in the HFC is designed for preliminary estimation of gamma-quantum flux near the filter of aerosol activity accumulated on the filter fabric.
It is recommended to use the HFC in the zone of possible scattering of gas-aerosol releases of radionuclides from the radiation facility.
The air-filtering unit carries out:
-continuous sampling of aerosols from atmospheric air onto the filter fabric;
-measurement of volumetric flow rate of air, pumping...
Specifications
MTBF
200
Overall dimensions of the MCUHOD, mm
500×500×260
Tolerance limits of relative error of measurement of air volume flow rate under normal conditions, %, not more than
max ±15 %
AC mains power supply of the VFU
167...268 V
Continuous operation time
24
Volumetric flow rate measurement range
250...1400
Average service life
8 a
Overall dimensions of HFC chamber, mm
700×800×670
Power consumption
500
