Vibration Controller A632 for Accurate Monitoring and Control of Vibrational Processes

Armoured glass

200 m/s2

VHF 2,3,5,10,30 Hz (user adjustable)

200 mm/s

1000 µm

screw terminals

±2 %

IEPE

RS485

IEPE 24 + 2 V

5.7 mA

4 ... 20 mA

± 5 V (signal)

AL1, AL2, AL3

0,1 (1) mm/sec

continuous exceeding of the set threshold by the informative signal within 0-9 s

lockout/self-recovery

6% reduction of vibration from the trigger threshold

0 or 20

Dry contact parameters <1A

Got it

Measured parameter, sensor conversion coefficient, values of set thresholds, error codes in case of cable breakage and sensor failure, setting of time of exceeding threshold values, relay contact states

< 200 mA

18...30 V

200 year

-40...70 °C

1
