Turning and screw-cutting machine 1M63N-8

Manual Metal Lathes

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Screw-cutting lathe 1M63N-10 Turning and screw-cutting machine 1M63H-5

The 1M63N-8 turning and screw-cutting machine is designed to perform a variety of turning operations, as well as cutting threads: metric, inch, modular and pitch.

Technical Specifications

Type of product according to PP RF 616	Turning and screw-cutting machines (universal, with CNC, CNC)
Height	1550 mm
Width	1780 mm
Length	10300 mm
Spindle speed limits	10...1250
Roughness of the cylindrical surface of the sample product after its finish machining	Ra2.5 µm
Accuracy class according to GOST 8-82	?
Total power of electric motors installed on the machine tool	16.22 kW
Main motion drive power	15 kW
Maximum torque on the headstock spindle	3.0 kNm
Highest cutting force Pz	22000
Speed of rapid transverse movements of the slide	2000 mm/min
Speed of rapid longitudinal movements of the caliper	5200 mm/min
Step limits for machinable pitch threads	112-0.5 pitch diametral
Step limits for machinable modular threads	0.25-56 module
Step limits for machinable inch threads	28-0.25 threads per 1 inch.
Step limits for machinable metric threads	1...224 mm
Longest longitudinal length of the slide stroke	7850 mm
Machine weight together with electrical equipment	10300 kg
Largest diameter of the workpiece to be mounted above the bed	700 mm
Largest diameter of the workpiece to be machined above the bed	630 mm
Largest diameter of the workpiece to be mounted and machined above the slide	350 mm
Longest workpiece length	8000 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
