System of dispatching control of radio channels SRMD-16

Manufacturer:
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Key Highlights

  • Made in Russia - engineered for durability
  • Suitable for challenging environments
  • Lower cost of ownership than European alternatives
  • Bulk orders available with volume discounts
  • Documentation and customs clearance assistance provided
The system of dispatch control of radio channels SRMD-16 is designed to provide equal access of up to 32 dispatchers/operators of one receiving and transmitting centre to 16 radio channels. The system provides: conflict-free conduct of bilateral radio conversations with subscribers of different radio channels by several dispatchers/operators; connection of up to 32 operator consoles; control of up to 16 radio channels from each operator's workplace; simultaneous listening to 4 selected radio channels at the operator's workplace. The system includes: operator console software SRMD-16 (up to 32 pcs.); base unit of central controller CK-BB SRMD-16 with boards of radio channels CK-PRK-4 SRMD-16 (up to 4 pcs.) and boards of operator consoles CK-PPO-4 SRMD-16 (up to 8 pcs.).

Technical Specifications

Type of power supply AC/DC
Number of power supplies 1 pc
Type of power supplies fixed
Power supply Built-in
Switch type Managed
Type of data transmission FC
Completeness Operator console PO SRMD-16; base unit of central controller CK-BB SRMD-16; radio channel board CK-PRK-4 SRMD-16; operator console board CK-PPO-4 SRMD-16.
Maximum number of consoles in the System 32 pc
Maximum number of controlled channels per operator workstation 16
Maximum number of simultaneously listened radio channels at the operator's workplace 4
Number of slots for radio channel cards in the central controller base unit 4 pc
Maximum number of radio channels supported by the radio channel card 4
Maximum number of operator consoles supported by the operator console card 4 pc
Average service life of the System 5 a
Number of slots for operator console cards in the central controller base unit 8 pc

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
