Screw Centre Lathe 1N65GF1

Manual Metal Lathes

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Screw Centre Lathe 1N65PF1-3 Turning and screw-cutting machine 1N65F1-3 Turning and screwcutting machine 1N65PF1 Turning and screw-cutting machine 1N65F1 Turning and screw-cutting machine 1N65P-3

Description

The machine is designed for all turning operations, including taper turning and thread cutting - metric, modular, inch

Specifications

Type of product according to PP RF 616 Turning and screw-cutting machines (universal, with CNC, CNC)

Height 1770 mm

Width 2200 mm

Length 6140 mm

Roughness of the cylindrical surface of the sample product after its finish machining Ra 2.5 µm

Main motion drive power 22 kW

Highest cutting force Pz 41000

Highest torque on the spindle 9.5 kNm

Speed of rapid transverse movements of the slide 1000 mm/min

Speed of rapid longitudinal movements of the caliper 3000 mm/min

Step limits for machinable modular threads 0.5-24 module

Pitch limits of inch threads to be cut 24-1/4 threads per 1 inch

Step limits of metric threads to be cut 1...96 mm

Maximum lateral movement of the slide 700 mm

Maximum longitudinal movement of the slide 2700 mm

Diameter of the cylindrical bore in the spindle 128 mm

Largest diameter of the workpiece to be mounted and machined above the slide 650 mm

Longest workpiece length 3000 mm

Largest diameter of the workpiece to be mounted above the bed 1000 mm

Digital Display Unit (DDU) UCI

Machine weight 13.1 t

Accuracy class of machine tools according to GOST 8-82 ?

Total power of electric motors installed on the machine tool 23.68 kW

Spindle speed limits 5...500

Largest diameter of the workpiece to be machined above the bed 1000 mm

Design Features GAP

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
