Rotary screwcutting lathe RTS117-16

Manual Metal Lathes

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Rotary screwcutting lathe RTS117-12 Rotary screw-cutting machine RTS117-10 Rotary screwcutting lathe RTS117-8

Description

The machine is designed for all turning operations, including taper turning and thread cutting - metric, modular, inch

Specifications

Type of product according to PP RF 616 Universal lathes and screw-cutting machines, with CNC, CNC)

Height 2000 mm

Width 2320 mm

Length 19410 mm

Roughness of the cylindrical surface of the sample product after its finish machining Ra 2.5 µm

Accuracy class of machine tools according to GOST 8-82 ?

Height of the tool to be mounted SBVVBG mm

Machine weight 30 t

Main motion drive power 30 kW

Highest cutting force Pz 41000

Highest torque on the spindle 9.5 kNm

Speed of rapid transverse movements of the slide 1000 mm/min

Speed of rapid longitudinal movements of the caliper 3000 mm/min

Pitch limits of modular threads to be cut 0.5-24 module

Pitch limits of inch threads to be cut 24-1/4 threads per 1 inch

Step limits of metric threads to be cut 1...96 mm

Maximum lateral movement of the slide 700 mm

Diameter of the cylindrical bore in the spindle 128 mm

Largest diameter of the workpiece to be mounted above the bed 1200 mm

Largest diameter of the workpiece to be machined above the bed 1140 mm

Largest diameter of the workpiece to be mounted and machined above the slide 900 mm

Longest workpiece length 16000 mm

Spindle speed limits 5...500

Maximum longitudinal movement of the slide 15600

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
