Available for Import
Mobile (portable) diesel compressor station ZIF-PV 10/1,0 (ARM9-50-04), on a trailer
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Drive type: internal combustion engine (ICE)
Nominal volumetric capacity, nm3/min, not less - 10
Final working pressure (overpressure), MPa - 1,0
Compressible gas - air.
Operating temperature range:
a) from minus 25 to +40 in basic configuration
b) from minus 40 to +40 with "North" package
c) from minus 25 to +50 in the "Tropic" package.
Operating mode: automatic
Oil content in compressed air at nominal mode, g/m3, not more:
0,0035
Rated power, kW - 78
Overall dimensions (DxWxH), mm - 2270*1244*1500
Weight, kg - 1570.
Under TU 3643-003-76260790-2020 "Compressor stations mobile (portable) diesel ZIF-PV types: MZA, ARM, ARM-MXD, ARM-MKXD. Technical conditions." produces a range of single-type diesel mobile compressor stations ZIF-PV, types: MZA, ARM, ARM-MXD, ARM-MCD, ARM-MCECD.
General parameters of the product line:
Compressor type: screw, piston, rotary, scroll.
On...
Technical Specifications
| Type | screw |
|---|---|
| Pressure | 1 MPa |
| Capacity, not less, nm3/min | 10 |
| Drive type | internal combustion engine (ICE) |
| Compressible gas | air |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
