Available for Import

MCS101-CPU-5R2F Network Controller for Fiber Optic Segments and RS-485 Applications

Automatic Control Devices

Manufacturer:SPBEX-MINING LLC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

?????????? MCS100-CPU-5R2F ?????????? MCS100-CPU-5R

Description

MCS101-CPU-5R2F is a control component of network fibre segments and RS-485 fieldbuses with application software.

Specifications

Assigned service life

10 years

Protection class against electric shock

III

Degree of protection against external influences

IP20

Operating temperature

-20...40 °C

Explosion protection marking

Ex ia op is I Ma U*

Programming system

CODESYS V3.5 SP17

Connectors

Power connector: 2-pole terminal block; RS-485 connector: 2-pole terminal block - 4 pcs, 1-pole terminal block - 2 pcs; optical connector: LC connectors

Data transfer rate

RS-485: 38,400 bps (default); 100BASE-FX: 100 Mbps

Rated DC voltage

B1/B8 2100/900 MHz V

Power consumption, max.

3 W

Standards

IEEE802.3u 100Base-FX, RS-485

Number of RS485 ports (lines):

5 pcs

Number of 100BASE-FX ports (lines):

2 pcs

Management

MODBUS RTU, UDP. TCP

Overall dimensions

153 x 126 x 34 mm

Weight, not more

0.4 kg

Mounting

DIN rail: W-type, width 35mm, recommended height 7.5mm/15mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
