Liquid Filtration Block KTR - Essential for Protecting Systems from Contaminants

The equipment is designed for filtration of liquids (water, oil, glycol solutions, methanol...) from mechanical particles in order to protect system components from damage. The unit consists of two filters connected by pipelines and shut-off and control valves switching the flow and can operate without stopping the technological process. When the filter element in the first filter housing becomes dirty, the flow can be easily switched to the other filter by means of a shut-off valve; at the same time, the dirty filter element can be washed back into the drainage system without depressurising the filter. Filters are produced according to TU 3646-002-75492423-2012, as well as according to the technical specification (questionnaire) under the parameters of the customer.
