Information registration complex "PATRUL" BRUA.463349.001-26

Wearable Video Systems

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

"Information registration complex "PATRUL" BRUA.463349.001-26 is designed to equip cars for transporting detained persons in administrative order. The set of equipment includes 8-channel cabinet server with GLONASS/GPS with the possibility of connecting an external GLONASS/GPS unit; remote control; 5 vandal-proof video cameras installed in the compartment for detainees (if available in the car); 3 vandal-proof video cameras for outdoor viewing; 7-inch video monitor; IR remote control repeater; removable hard drive up to 1024 Gbytes and SD card - 32 Gbytes; a box for the server; a set of installation cables; CD with software to work on a PC; CD with manuals for operation and installation of the complex. The main advantages of the device: Constant audio-video recording inside and outside the car; The design of the video server excludes unauthorised removal and deliberate damage to the elements of the product; Compression H.264; Vandal-proof video cameras.

Specifications

Data transfer rate 100

Compression standard H.264 compression

Power consumption of the product without external devices (microphones, TV cameras and hard disk) Built-in memory card slot, support microSD/SDHC/SDXC card (up to 256GB); manual recording/alarm recording W

Audio source Built-in microphone

Video source standard, color or black and white camera colored

Supported memory card capacity 32

Supported memory cards SD

Number of recordable video channels 8 pc

Number of audio sources 1 pc

The product is powered by AC mains voltage 8...36 V

MicroSD card capacity 32

Supported Ethernet baud rate 100

Codecs used H.264

Number of frames per second (adjustable) 25

Maximum video frame size, pixels 1920?1080

Number of audio channels 1 pc

Number of video channels 8 pc

Number of USB ports 2 pc

Number of microSD card slots 1 pc

HDD disk capacity 1024

Supported memory cards class 10

Maximum current consumption of one video camera, Ma 400

Operating temperature From minus 30 to plus 60 °C

Network port 1 RJ-45 port (10/100 Mbps)

HDD disk type 2 x SATA HDD (2.5") in vibration-proof basket

Record type Video / Video and Audio

System Resources Recording, playback, backup, remote access, search mode - time/date (accurate to the second), alarm mode

DC power supply 8...36 V

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
