High Voltage Power Supply SHVLP Series for Rack Mounting

DC Power Supplies

Manufacturer: PARAMERUS LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The SHVLP series of high-voltage power supplies for server rack mounting includes models with positive and negative polarity with output voltage from 1 kV to 60 kV and power from 10 W to 60 W. All models are equipped with a complex of protective features. All models are equipped with adjustable threshold protection and three modes of operation: current, voltage and power regulation, allowing the devices to be used for a wide range of industrial and research applications.FEATURESInput power protectionOverload and short circuit protectionOver/under voltage output protectionArcing discharge protectionActive power factor corrector with 99% efficiencyAnalogue interface with opto-coupling (DA-15)Analogue interface compatible with Spellman interface (JBI STR 50)Support for RS-232 digital interfaces, RS-485, USB, GPIB, EthernetIntuitive user softwareManufacturing, support and service - RF

Specifications

Output voltage setting accuracy

0.05 %

Instability of output voltage when input voltage changes

0.005 %

Digital control interfaces

RS-232; RS-485; USB; GPIB; Ethernet

Setting the output voltage/current

Multi-turn potentiometer on the front panel

Safeguards

By input power supply, undervoltage and overvoltage, output current exceeded, output power exceeded, output short circuit, output arc discharge, operating temperature exceeded

Instability of output current

0.01 %

Output current setting accuracy

0.05 %

Instability of output voltage when load changes

0.005 %

Output voltage adjustment

0 to Vout max

Polarity

Positive, Negative or Customizable

Output voltage ripple

0.05 %

Output power

10...60 W

Maximum output voltage

1000...60000 V

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
