Available for Import

GSK3-230/10 3+1 C (LT) surge protection device, cat.no.300 137.

Surge Protection Devices

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Protection device against impulse overvoltages GSK3-230/10 3+1 C, cat.no.300 037.

Description

Four-pole modular surge arresters of test class III, combined type. U0 = 230 V AC. Uoc (1,2/50) = 6 kV. They are installed within II - III lightning protection zones (in accordance with GOST R IEC 62305-1 and SO-153-34.21.122). Designed to protect equipment from residual surge surges for circuits with TNS type earthing system. Visual control of the operating state of the surge arresters is carried out by means of a red-coloured indicator on the replaceable modules. For remote control the devices are equipped with a dry contact for remote signalling.

Specifications

maximum operating current (max. 25 A

Surge protection class III

Rated operating voltage Un 230 V

Housing material Polyamide PA6

Weight 0.472 g

Dimensions, WxWxH 70x102x79 mm

Number of channels 1 pc
