Available for Import

Frequency transfer unit BHR-1-29/18,8-3000-N-D/D

Telecom Equipment Accessories

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

The device is designed to transfer the frequency spectrum from Ka band to K band, with the ability to adjust the signal gain up to 60 dB. The filter at the output provides filtering of conversion products, sum and difference of received harmonics, suppression of the mirror channel. The bandwidth is 3000 MHz.

Technical Specifications

Input frequency range	27500...30500
Output frequency range	17300...20300
Transmission ratio adjustment range	-60...0
Frequency response irregularity (max.)	2
Noise figure (max.)	33
1dB compression point output power (at least)	0.001 W
Mirror channel suppression (dBn, not less)	60
Frequency of the external reference oscillator	10
Internal reference oscillator	Got it
Power supply voltage	12...24 V
Power consumption (max.)	13 W
Remote monitoring and control	Yes, via DB-9 connector using RS-485 standard.
List of controlled parameters	Status (faulty/faulty), PLL capture (there is capture/not), internal unit temperature (C), current current consumption (A)
Weight (max.)	2000 g

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
