Extended anode earthing electrode of modular construction Anode MINADAGS ER-7 RPDMUS brand

Low-Voltage Electrical Panels

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Extended modular anode earthing electrode MINADAGS ER-7 EPDMUS Anode Extended modular anode earthing electrode MINADAGS ER-7 EPDM Extended modular anode earthing switch MINADAGS ER-7 EPDKMAMUS Extended modular anode earthing electrode MINADAGS ER-7 RPDMUS Extended modular anode earthing electrode MINADAGS ER-7 EPDKMAM

Description

Extended flexible low-soluble anode earth electrodes (hereinafter - PA) for application in the system of current-pumping anode earths of installations of cathodic protection of metal structures and constructions against underground corrosion in aqueous media. PAs provide long-term, uninterrupted and efficient flow of protective current from the cathodic protection station through the ground to the protected structure. PAs are designed for operation in soils with any specific electrical resistance, especially in soils with high specific electrical resistance (more than 100 Ohm-m). In soils with low resistivity (less than 100 Ohm-m), double-layer PAs with current-carrying sheaths are used, as well as combinations of PAs with distributed or concentrated anode earth electrodes.

Specifications

Cross-section of copper conductor of the operating element and supply cable, mm² 10; 16; 25; 35; 50.

Type of construction ER-7

Material of the electrically conductive sheath of the operating element P - carbon-filled electrically conductive polyolefin (thermoplastic or reactoplastic)

Conditions of use P - subsurface anode

Design and method of placement E - extended, placed in the ground along the protected structure

Presence and type of electrically conductive carbon backfill (activator) - without conductive backfill

PA design - standard version

Reinforced design of the working element construction RS - hardened core

Working element length, m 5-600

Nominal outer diameter of the working element on electrically conductive polymer sheath, mm 14,7; 15,8; 17,6; 18,4; 20,1; 18,7; 19,8; 21,6; 22,4; 24,1

Tinning of the copper core of the operating element and the lead cable - non-tinned core; l - tinned core.

Length of cable outlet at the beginning of the work item, m any length

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
