DT-0.6-500 Throttle Transformer for Railway Applications and Electric Systems

Throttle-transformer of DT-0, 6-500 type is designed for installation on railway sections equipped with AC autoblocking and DC electric traction, as well as for docking of electric traction systems. The choke-transformer is designed for passing the rated DC current of 500A in electric traction through each section of the main winding. The middle winding lead is designed to carry a current rating of 1000A.

The choke-transformer operates in the temperature range from minus 50C to plus 45C and is manufactured in climatic version U, category 1 according to GOST 15150-69. According to the method of protection of a person from electric shock the choke-transformer belongs to class 0 of GOST 12. 2.

007.
