Disc Varistor 40V for Surge Protection - Model VR20D680K

Manufacturer: HAKEL OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

VR20D680K - varistor of KVS series, 40 V, 2.0 kA (8/20), zinc-oxide, disc-shaped with unidirectional (radial) wire leads, protected, not insulated.

Maximum disk thickness

8 mm

Maximum disk diameter

23 mm

Operating temperature range

-60...85 °C

Maximum pulse energy (2 ms)

20.4

Permissible amplitude of a single current pulse (8/20 µs)

2000 A

Maximum continuous operating voltage

56 V

Maximum AC operating voltage

40 V

Classification rated voltage at 1 mA current

68 V
