Conveyor Type X-ray Scanner TS-SCAN 6575 for Baggage Inspection

Radiation Inspection Devices

Manufacturer: DIAGNOSTIKA-M LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The TC-SCAN 6575 is designed for use in the inspection of baggage and medium-sized objects with maximum dimensions of 65×75cm (W×H).

Widely used at checkpoints of institutions and airports during entry control. Objects are scanned from one or two angles, which increases the detection of dangerous or prohibited items. The machine features an improved material recognition methodology, automatic selection of suspicious areas and an ergonomic operating concept with programmable priority keys.

TC-SCAN6575 conveyor-type X-ray telescope has received a certificate of compliance with the requirements of the Government Decree ? 969. The received certificate certifies that the X-ray telescope of conveyor type "TS-SKAN6575" can be used at all transport infrastructure facilities to ensure security.

Specifications

Type of product according to PP RF 616

Instruments and other instruments for measurement, control and testing

Weight, kg

1050 kg

Overall dimensions (DxWxH), mm

2834,4?1361?1653 mm

Power consumption, kW

1 kW

Number of beams (angles)

1 or 2

Work cycle

Round-the-clock

Maximum/operating current, A

0,001/0,0007 A

Maximum/operating voltage, kV

160/140 kV

Penetration capacity (steel), mm

guaranteed 32, typical 36 mm

Resolution (by wire), mm

Guaranteed 38 AWG (0.1 mm), typical 40 AWG (0.08 mm) mm

Conveyor speed, m/s

0.2

Conveyor height from the floor, mm

334 mm

Maximum dimensions of the object (WxH), mm

650×750 mm

Tunnel size (WxH), mm

not less than 650×750 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
