CNC Chuck-Type Lathe Machine Model 16R50F3 for Precision Machining

CNC Metal Lathes

Manufacturer: RSZ LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The CNC chuck centre lathe model 16R50F3 is designed for turning in centres and chucks of parts with straight, stepped, curved profile and for thread cutting. The machine has a large range of feeds and spindle speeds, which fully provide the choice of standard cutting modes for machining workpieces from different construction materials. The machine is equipped with a large range of manual and mechanised chucks of various diameters, lunettes, boring bars for various machining lengths, interchangeable fixtures for grinding, knurling, etc.. The accuracy class of the machine is P according to GOST 8-82. Due to the presence of an operational control system there is a possibility of cycle or manual control, which allows to use the machine in single production, especially with periodically recurring orders. It is also possible to work according to the control programme.

Specifications

Type of product according to PP RF 616

Universal screw-cutting lathes with CNC, CNC

Type of product according to PP RF 616

Universal lathes and screw-cutting machines, with CNC, CNC)

Length

5200 mm

Width

3400 mm

Height

2000 mm

Machine weight, not more

6100 kg

Total power of electric motors installed on the machine tool

38 kW

Movement of the tailstock quill per revolution of the handwheel

6 mm

Spindle speed limits

8...1600

Height of the tool to be mounted

32 mm

Maximum weight of the workpiece to be installed in centers and lunettes

3500 kg

Maximum length of the workpiece to be processed, not less than

1500 mm

The largest diameter of the workpiece mounted above the bed, not less than

660 mm

The largest diameter of the workpiece installed above the slide, not less than

900 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
