Cells of CSR series CSR "Onega" 10, 20 kV

High Voltage Switchgear

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

"Onega" 10,20 kV Series CSR prefabricated single-sided service cells of "Onega" series are designed for completing switchgears (switchgear) with voltage of 10,20 kV of three-phase alternating current with frequency 50 Hz, in networks with isolated or earthed through arc-extinguishing reactor or resistor neutral.

Specifications

Width 300...750 mm

Height 2010...2235 mm

Depth 1050 mm

Nominal voltage 10...20 kV

Highest operating voltage 12...24 kV

Rated current of busbars 630...1250 A

Rated current of line terminals 630...1250 A

Rated current of fuses up to 200 A

Rated current of circuit breakers 1000...1250 A

Rated current of load disconnectors 630 A

Rated current of disconnectors 630...1250 A

Rated current of current transformers 5...1250 A

Rated tripping current of circuit breakers 20000 A

Thermal endurance current at 3s flow time, kA 20000 A

Electrodynamic resistance current 51000 A

Rated voltages of control and auxiliary circuits, at direct current 24...220 V

Service life 30 a

Degree of protection according to GOST 14254 IP31

Weight Up to 800 kg

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
