Available for Import

Basic module kB.M-7

Automatic Control Devices

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Basic module kB.M-3

Description

Designed for use in automated process control systems as a device to expand the number of analogue and discrete inputs and outputs of control modules Komega (kV.D or kV.EG), polling third-party devices via RS485. I/O: 4*AI, 4*AO, 8*DI/DO (transistorised), 2*DO (triacs), 4*DO (relays).

Specifications

Compatible with modules Comega Software and Hardware Complex devices, Modbus RTU, CAN network devices

Number of channels 22 pc

Interface type RS485 + I2C (system bus)

Software platform For development of control algorithms: Codesys, kStudio. For dispatching: SuperSCADA, kServer/kPlayer

System Characteristics ARM Cortex-M4, 120 MHz, Flash - 512KB, SRAM - 96KB, Non-volatile memory type (ROM) - FRAM, Memory size - 32KB, Real-time clock

Power supply, V DC 11...36

Analog inputs 4 pcs, configurable, progranular selection of any input type: 0 - 20 mA / 0 - 10V / 0 - 2500 mV / 0 - 10 kOhm. ADC digit capacity - 24 bits

Analog outputs 4 pcs., configurable, prograde selection of any output type: 4 - 20 mA / 0 - 10 V. DAC digit capacity - 12 bits

Binary inputs outputs, configurable 8 pcs., dry key input or transistor output, DC up to 24 V, up to 2 A

Discrete outputs 2 pcs., triac, AC 420 V, 1 A

Network function to be performed Slave

Item ge3035122-07

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
