Autonomous audio recorder OSA S1PL for Passenger-Cashier complex
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Autonomous audio recorder OSA S1PL is used for autonomous, without the participation of the operator, audio recording from the intercom Passenger-Cashier, through the glass partitions with automatic recording of conversations on a memory tap with subsequent upload to FTP server.The possibility of choosing the type of intercoms and recording system allows you to form a set for different tasks and budget.Audio recorder is made in the form of a separate board for installation inside the intercom DD-205T-HF, it can not be disconnected, it will record everything.Possibility of selecting the type of intercoms and recording system allows you to form a set for different tasks and budget.Audio recorder is made in the form of a separate board for installation inside the intercom DD-205T-HF, it can not be disconnected, it will record everything.Possibility of selecting the type of intercoms and recording system for different tasks.
Technical Specifications
| Acoustic range | 10 m |
|---|---|
| Number of channels | 1 pc |
| Type of sound source | Intercom DD-205T-HF, DD-215T-HF |
| Connecting an audio source | Soldering to board pins |
| Network interface | Ethernet, 100MBit |
| Device power supply | 9...15 V |
| Current consumption | In sleep mode up to 270 µA; in write mode up to 20 mA |
| Execution | In the form of a board for installation inside the intercom system |
| Operating temperature range | 0...70 °C |
| Place of storage of records | Memory card, FTP server |
| Memory card type | SD HC and XC standards, Class 10 |
| Supported memory card capacity | 16...512 |
| Hot swap memory card | Allowed without loss of information |
| Upload to FTP | Scheduled, at the end of file recording |
| Connecting to the device | Over Ethernet, RJ45 connector |
| Protocol used | TCP, HTTP |
| Differentiation of access rights | Administrator - full rights. |
| Name of the software package to be used | R-Monitor (under Windows 7, 8, 10) |
| Interface | Russian-speaking |
| Recording Modes | Constant, scheduled, acousto-powered |
| Remote monitoring | Possible online via network and Internet |
| Recording AGC adjustment range/step | 0...45 |
| Recording AGC time constant | 0.1...6 |
| An algorithm for compressing audio information: | Without compression. RSM 16 bits, mono |
| Dynamic range of the recording channel | 96 |
| Non-uniformity of the amplitude-frequency response | 1.6...1.8 |
| Nonlinear distortion factor | 0.8...0.95 % |
| Signal-to-noise ratio | 80 |
| Sampling frequency | 16 |
| Operating frequency range | 100...7200 |
