Attenuator controlled electromechanical D6M-18-01P

Electrical Measurement Instruments

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Attenuator controlled electromechanical D6M-26-03P Attenuator controlled electromechanical D6M-26-13P Attenuator controlled electromechanical D6M-18-11P

Description

The D6M series attenuators are designed to attenuate microwave signal power in the range from 0 to 81 dB in 1 dB steps. The operating frequency range is from 0 to 26.5 GHz.
The D6M Series controlled electromechanical attenuators are a complete solution, allowing multiple measurements with different attenuation in a single connection. The basic unit is equipped with 4 external outputs to which additional electromechanical attenuators can be connected, thus extending the range of applications.
Built-in SCPI-command system allows to automate measurements with transition by microwave signal power level. The instrument is controlled both from the front touch panel and remotely from the controlling PC via LAN, USB, RS-232 interfaces.
Attenuators of D6M series are widely used in the development, research and adjustment of units, RF and microwave equipment, including as part of automated control and measurement systems.

Specifications

Type by set of reproducible values Stepped

Connection type Coaxial

Maximum input power 1 W

Switching time, ms 40

Number of switching cycles for attenuators 100000

Insertion attenuation 3...5

Connector connection type Type III, receptacle

View by frequency range Radio measurement

Defense TR CU 020/2011

Equipment Additional coaxial transitions and cable assemblies can be included on request

Maximum value of the frequency range 0...18

Mark D6M-18-01R

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
