AGAT 01.05.02 Modular Storage Rack for Efficient Organization

Size: 1540x400x1930mm. Collapsible frame is made of 20x20x1,5mm pipe. The frame consists of the following parts: 1) The connecting slide is a tube 20x20 with a length of 360mm with one hole at both ends with a diameter of 10.5mm.

2) Shelf "A" is installed around the perimeter of the base of the rack - tube 20x20 length 360mm with two holes at both ends with diameter 10,5mm 3) Shelf "B" is installed in the base of the rack inside - tube 20x20 length 360mm with two holes at both ends with diameter 10,5mm for the set screw and two holes for the rivet thread m6 to install the adjustable support. 4) Aluminium brackets, adapters connecting all the slides. Brackets of 4 types depending on their location in the frame.

Inserted inside the shelf - tube 20x20 and tightened through the threaded hole in the bracket and the shelf. Complete with shelf 356h398h16 -7pcs, drawer 356h398h120 -1pcs, cube 356h398h358 -4pcs. Shelves, drawers and cubes made of LDFP 16mm.
