Available for Import
Vacuum brazing furnace R320C
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Technical Specifications
| Product loading height for version L | 100 mm |
|---|---|
| Product loading height for version M | SBVVBG mm |
| Height for version L with top IR heating option | 1322 mm |
| Height for version L | 1296 mm |
| Height for version M | 1245 mm |
| Uninterruptible power supply | Option |
| Soft pumping | Option |
| Remote control via Wi-Fi from an Android device | Option |
| Separation of management rights | In stock |
| Number of recipes in the program | 1000 pc |
| Flux trap | Option |
| Optional top IR heating | Option |
| Additional gas supply line | 4 pcs. (optional) |
| Maximum pressure with option | 4 Bar. |
| Maximum pressure inside the working chamber | 1,5 Бар |
| Residual pressure with high vacuum pumping option | 0.001 Pascal |
| Gas supply lines equipped with digital PWGs | 2 pc |
| Volume of the UNFU barbiter | 300 |
| HCOOH (formic acid) vaporizer | In stock |
| Vacuum pump capacity | 10 cubic metres per hour |
| Vacuum pumping system | Oil-free |
| Vacuum limit of the integrated volute pump | 1 |
| Cooling rate | 250 C/min |
| Heating rate | 180 C/min |
| Number of thermocouples for temperature control | 2 pc |
| Maximum heating temperature | 450 °C |
| Working area length | 320 mm |
| Working area width | 320 mm |
| Heating type | Heated copper table |
| Viewing window diameter | Flat grinder, Specialised grinder mm |
| Viewing window | 1 pc |
| Weight | 400 kg |
| Working chamber material | Aluminum alloy |
| Mains frequency | SBVVBG |
| Power supply voltage | 380 V |
| Rated power | 25 kW |
| Length | 798 mm |
| Width | 800 mm |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
