Available for Import
Underwater teleoperated uninhabited apparatus "RB-600"
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
The underwater teleoperated uninhabited apparatus "RB-600" is designed for inspection, research and light underwater technical works at depths up to 300 metres. The equipment is standardly completed with underwater module, cable reel with cable, surface control unit. The underwater module is equipped with high quality video system (front, rear video cameras), powerful light system with smooth intensity control, auto-holding course and depth functions, laser designators.
Technical Specifications
| Length of apparatus | 664 mm |
|---|---|
| Unit width | 445 mm |
| Height of apparatus | 413 mm |
| Weight of aerial apparatus | 30 kg |
| Number of vertical motors | 2 pc |
| Number of horizontal motors | 4 pc |
| Free orientation system | Three-axis accelerometer, Roll Differential Sensor, Three-axis Gyroscope, Control Controller |
| Number of side (lag) motors | 1 pc |
| Type of motor screw | Reversible |
| Speed of marching engine max. | 1.5 |
| Vertical motor speed max. | 0.5 |
| Speed of lagging motor max. | 0.5 |
| Type of thrusters | Dry thrusters on magnetic couplings |
| Length of Kevlar fibre reinforced cable rope | 400 m |
| Cable rope breaking force | 460 kg |
| Monoblock | In a plastic, impact-resistant HPRC2600 case. |
| Management | SONY PS4 |
| Display | 1 HDMI video output integrated LED monitor 19" |
| Panel Connectors | USB 2.0 - 2 pcs. |
| Built-in PC | Intel NUC, SSD 256 Gb |
| Alternating current | 220-240V, 50Hz |
| Power consumption | 2000 W |
| Type of light element | LED lighting element |
| Adjustment of luminescence intensity | availability |
| Front lights (number, power) | 4 pcs. each ~ 1400 Lm (20W) |
| Luminaires on chamber platform (quantity, power) | 2 pcs. of ~ 700 Lm (10W) |
| Rear lights (number, power) | 4 pcs. of ~ 700 Lm (10W) |
| Количество передних видеокамер | 1 pc |
| Maximum video resolution of front camera footage | 1920 ? 1080 |
| Tilt angle of the front camera platform | ±90 |
| Количество задних видеокамер | 1 pc |
| Maximum video resolution of rear camera footage | 1920 ? 1080 |
| Tilt angle of rear video camera | ±90 |
| Power distribution board | availability |
| Pilot sensors | availability |
| Leak sensors | availability |
| Outboard water temperature sensor | availability |
| Digital compass (magnetic) | availability |
| Course stabilisation | availability |
| Depth stabilisation | availability |
| Water operating temperature | -5...40 °C |
| Depth sensor, m | Sensitivity 0,1 |
| Number of laser designators to estimate the size and distance of objects underwater | 4 pc |
| Cable tether reinforced with Kevlar fibre in water | Neutral buoyancy |
| Air operating temperature | -15...45 °C |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
