Typical set of laboratory equipment "Physics-Electricity and Magnetism" E&M

The set of laboratory equipment is designed for laboratory work on the section "Electricity and magnetism" of the discipline "Physics" in secondary and higher educational institutions.
Composition:
1. Desktop construction;
2. Generator unit (isolated generator of signals of special form, regulated stabilised power supply "0...+15V", stabilised voltage source "+15V", stabilised voltage source "-15V");
3. Multimeter unit (unit with two digital multimeters powered by AC 220 V 50 Hz and one arrow voltmeter);
4. Electrical field simulation unit with two conductive plates;
5. Set field (a panel for assembling the circuits under study with 123 contact sockets for connecting miniblocks and connecting wires);
6. Set of miniblocks (18pcs): "Resistor 10 Ohm", "Resistor 100 Ohm", "Resistor 470 Ohm", "Capacitor 1,0 µF", "Capacitor 0,1 µF", "Capacitor Cx", "Inductance 16 mGn",
"Lx inductance", "Key", "C...
