Turbine flowmeter-counter RVSH-TA-10-U21

Water and Liquid Meters

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Turbine flowmeter-counter RVSH-TA-50 Turbine flowmeter-counter RVSH-TA-100 Turbine flowmeter-counter RVSH-TA-65 Turbine flowmeter-counter RVSH-TA-80 Turbine flowmeter-counter RVSH-TA-32

Turbine flowmeter-counter RVSH-TA-10-U3 Turbine flowmeter-counter RVSH-TA-20 Turbine flowmeter-counter RVSH-TA-150

Description

Flow meters of RVSH-TA type are designed for commercial and on-farm metering of quantity (volume) and flow in the range from 0,08 to 1900 m3/h of Newtonian liquids with kinematic viscosity from 0,6 to 300 mm2/s (cSt), temperature from minus 50 to plus 250 °?, pressure from 0,4 to 40 MPa.
According to the operating conditions flow meters are designed for use in stationary installations, on land mobile and portable means of refuelling and pumping during their operation on site, as well as at facilities where their use is possible according to the operating conditions.
Field of application: commercial and on-farm accounting in power, chemical, oil, oil refining industries and other spheres.
Relative error tolerance limits: ±0,25; ±0,50; ±1,00%.

Specifications

View Turbine counter flowmeter RVSH-TA-10-U21

Connection type socket

Nominal bore diameter 10 mm

Lower limit of flow measurement 0.12

Upper limit of flow measurement 3

Viscosity range, mm2/s 0.6 to 300

Medium temperature range, °? minus 50 to plus 250

Relative error tolerance limits 0.25 %

Rated working pressure 25 MPa

Type of product according to PP RF 616 Industrial control and measuring machines
