Transport detector radar "SPEKTR-M"

Radar Equipment

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

Transport detector radar "SPEKTR-M" is designed for:
- measuring the speed of vehicles (hereinafter - TC) in the control zone;
- measuring the location of the vehicle in the control zone of the IP;
- measurement of time synchronised with UTC(SU) time scale corresponding to the moment of measuring the speed and location of the vehicle;
- classification of TCs by length;
- measurement of time intervals;
- measurement of the coordinates of the Detector location;
-classification of vehicles by length;
- determination of statistical parameters of traffic flow movement: intensity, occupancy, average speed and average interval between vehicles.

Specifications

Operating frequency of radiation 24.05...24.25

Number of controlled lanes, up to B1/B8 2100/900 MHz pc

Number of accompanied TC, up to 128 pc

Measuring range of vehicle speed 1...350

Limits of permissible absolute error of measurements of vehicle speed, km/h ±1

Measuring range of distance to moving vehicle, m 1-170 cars; 1-230 lorries

Limits of permissible absolute error of distance measurements to TC, m ±1

Horizontal viewing angle -10...10

Viewing angle in the vertical plane -20...20

Number of TC gradations, not less than 7

Probability of vehicle misclassification, not more than 10 %

Probability of missing TC, not more 4 %

Rated DC supply voltage 8...18 V

Consumption power at rated supply voltage, not more than 8 V

Weight of detector without mounting bracket, not more 0.6 kg

Length of detector without mounting bracket, max. 130 mm

Width of detector without mounting bracket, max. 85 mm

Height of detector without mounting bracket, max. 70 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.

Save Your Time

Share your requirements for a quick response!

Looking for

Quantity

Your mobile

Instant response in 15 minutes

Best wholesale prices guaranteed

Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
