Tractor-Towed Feed Distributors KTP-6 for Effective Livestock Feeding
Manufacturer:
KMZ LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
Tractor semi-trailer feeders are designed for transporting and distributing fodder on farms and cattle fattening sites. They are produced in modifications - distribution on one or two sides, Hopper volume - 6 cubic metres. Weight of transported feed - not more than 4 tonnes.
Specifications
Type of product according to PP RF 616
Equipment for agriculture, not included in other groupings
The pneumatic brake actuator must be tight at air pressure
0.6 MPa
The dispenser is equipped with
Service brake system with action on wheels of front axle with pneumatic brake drive; Parking brake system with mechanical drive on wheels on front axle
The design of the dispenser shall ensure
Possibility of readjusting the drive of the longitudinal conveyor for rear unloading of the body; Automatic disconnection of transmission mechanisms and working bodies in case of emergency overloads.
Process reliability factor
1
Labor intensity of aggregate compilation
0.1
Feed losses during distribution
1 %
Specific weight per unit of capacity
230
Uneven feed distribution between sides
5 %
Uneven feed distribution along the length of the feed line
20 %
Deviation from the set feed distribution rate
5 %
Feed distribution rates
10...25
Feed distribution speed
80...480
Operating speeds
25
Required width of the turning lane
13.5 m
Minimum turning radius of the machine
6500 mm
Power consumption for the drive of the working elements
7.5 kW
Drive of working elements
From tractor PTO
Type
semi-trailer
Number of personnel operating the unit
1
Average service life before write-off
7 year
MTBF
300
Transport speed
25
Ground clearance
300 mm
Track
1560 mm
Tire type
9,00-16
Type of suspension
Две оси с рессорами; Одна ось с рессорами; Одна ось без рессор; Балансир
Type of feed distribution
On the right side; On two sides simultaneously
Body capacity
6.7
Gross weight
3600 kg
Payload
2300 kg
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
