TC-SCAN 6575 conveyor-type introscope
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Technical Specifications
Type of product according to PP RF 616 | Instruments and other instruments for measurement, control and testing |
---|---|
Weight, kg | 1050 kg |
Overall dimensions (DxWxH), mm | 2834,4?1361?1653 mm |
Power consumption, kW | 1 kW |
Number of beams (angles) | 1 or 2 |
Work cycle | Round-the-clock |
Maximum/operating current, A | 0,001/0,0007 A |
Maximum/operating voltage, kV | 160/140 kV |
Penetration capacity (steel), mm | guaranteed 32, typical 36 mm |
Resolution (by wire), mm | Guaranteed 38 AWG (0.1 mm), typical 40 AWG (0.08 mm) mm |
Conveyor speed, m/s | 0.2 |
Conveyor height from the floor, mm | 334 mm |
Maximum dimensions of the object (WxH), mm | 650×750 mm |
Tunnel size (WxH), mm | not less than 650×750 mm |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
