Tandem axle semi-trailer PR-18L (9412L) with axle unit BPW HSFALM 9010-15 V36 61.68.361.147QS

Trailer-sortyment carrier-platform with cones. Reinforced chassis made of two longitudinal members of I-beam section, connected by cross beams; Longitudinal and cross beams are made of low-carbon steel; Reinforced drawbar with fixing through silentblocks, located in the centre, (diameter of coupling pivot loop ø50, two positions of drawbar 750 mm and 950 mm), closed with corrugated sheet from above; Front bogie welded, connected to the chassis through reinforced slewing ring; Central lubrication system of slewing ring; Reinforced rotary bogie lock (in the form of a pin); On the end of the frame from the front there is a pipe for lifting the trailer with a manipulator; The position of the cones is adjustable along the trailer; The fasteners for tightening the load are installed rigidly on the frame; The fastening mechanism is made in the form of a winch (installed on bolts); Belt locking mechanism with a cable (for convenient release of the forest from the tightened straps); The floor is made of laminated multilayer birch plywood, corrugated surface
