Available for Import
Steel Reverse Rotation Check Valve K0, ZO for Effective Flow Management
Manufacturer:
SAZ CJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Steel butterfly valves (valves):
PN 1,6 DN 50, 80, 100, 150, 200, 250, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 2,5 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 4,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 6,3 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 8,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 10,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 1000, 1200;
PN 12,5 DN 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 16,0 DN 100, 150, 200, 250, 300, 350, 400,
designed for installation in order to prevent reverse flow of working medium on main oil pipelines and oil product pipelines, in technological schemes of pumping stations and tank farms in areas with seismicity up to 10 points inclusive on MSK-64 scale and providing ......
PN 1,6 DN 50, 80, 100, 150, 200, 250, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 2,5 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 4,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 6,3 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 8,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 10,0 DN 50, 80, 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 1000, 1200;
PN 12,5 DN 100, 150, 200, 250, 300, 350, 400, 400, 500, 600, 700, 800, 800, 1000, 1200;
PN 16,0 DN 100, 150, 200, 250, 300, 350, 400,
designed for installation in order to prevent reverse flow of working medium on main oil pipelines and oil product pipelines, in technological schemes of pumping stations and tank farms in areas with seismicity up to 10 points inclusive on MSK-64 scale and providing ......
Specifications
Type of product according to PP RF 616
Control valves, return valves, safety valves, distribution and mixing valves, separating valves, combined valves, reducing valves
Nominal diameter
50, 80, 100, 150, 200, 250, 300, 350, 400, 500, 600, 700, 800, 1000, 1200 mm
Nominal pressure
1,6; 2,5; 4,0; 6,3; 8,0; 10,0; 12,5; 16,0 MPa
Connection type
flanged, welded
Designation
ko,zo
Share your requirements for a quick response!
Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer
Delivery & Payment
Shipping Terms
Delivery Time
Sea freight: 30-60 days (depending on destination)
Air freight: 14-21 days (for urgent orders)
Payment Methods
