Software and hardware complex PTC TITAN CONTROL 1000

Automatic Control Devices

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

PTC "TITAN CONTROL 1000" is a programmable logic controller with a variable composition of modules. PTC is designed to measure, control and regulate the parameters of discrete, periodic and continuous technological processes, as well as for the exchange of data and commands with automated systems of operational dispatch control. TITAN CONTROL 1000 PTC is designed for construction of small and medium-sized automated systems for various purposes by the number of input/output signals. The field of application of TITAN CONTROL 1000 PTC is light industry, agricultural products processing, housing and communal services, water treatment, water disposal, water treatment plants. It is allowed to use PTC in systems of technical accounting of resources, control systems of engineering systems of knowledge and constructions, in commercial systems of ventilation and cold supply.

Specifications

Current consumption on the internal power supply bus 0.15 A

Maximum number of expansion modules in a system with additional remote I/O modules 100

Power redundancy Built-in ioniser for saving current parameters and normal shutdown of the computing module

DC overvoltage protection Got it

Galvanic isolation of external sensor circuits and internal power supply circuits of computing components Got it

Weight, not more 0.06 kg

Installation dimensions (WxHxH), max. B1/B8 2100/900 MHz mm

Weight, not more 0.15 kg

Installation dimensions (WxHxH), max. 55 mm

Type of construction Modular (DIN rail)

OS Linux based on Ubuntu distribution with Real Time Patch

Interfaces 1xRS-485, 1xEthernet

Time synchronization Через NTP/SNTP сервер

Video output 1xHDMI 1.4 with HDCP 1.2

Audio input Dupont 2.54 connector on PCB for external microphone connection (optional)

Audio output 3.5mm jack (optional), HDMI

USB ports 2xUSB 2.0

Power supply voltage, direct current 24 V

Number of channels 2

ADC digit capacity B1/B8 2100/900 MHz

Nominal range 0...1600 ohm

Galvanic insulation 500 V

Module consumption via 5 V bus 1 W

Module consumption via 24 V bus 8 W

Resolution of serial approximation ADCs 16

Polling time of all channels 0.1

Thermoresistance PT100 (2-, 3-, 4-wire) PT1000 (2-, 3-, 4-wire)

Presence of polarity reversal alarm Yes, indication on the module.

Measuring current 0.0004 A

Number of channels 8

ADC digit capacity B1/B8 2100/900 MHz

Nominal range 0...10 V

Galvanic insulation 500 V

Module consumption via 5 V bus 1 W

Module consumption via 24 V bus 8 W

Resolution of serial approximation ADCs 16

Polling time of all channels 0.1

Input resistance of current measurement channels, kOhm, not less 100000 ohm

Number of channels 8

ADC digit capacity B1/B8 2100/900 MHz

Nominal range 0...0.02 A

Galvanic insulation 500 V

Module consumption via 5 V bus 1 W

Module consumption via 24 V bus 8 W

Input resistance of current measurement channels 100 ohm

Resolution of serial approximation ADCs 16

Presence of polarity reversal alarm Yes, indication on the module.

Polling time of all channels 0.1

Sensor type Passive with external PSU

Permissible supply range 21...30 V

Number of channels 4

DAC resolution B1/B8 2100/900 MHz

Nominal range 0...10 V

Insulation voltage 500 V

Module consumption via 5 V bus 1 W

Module consumption via 24 V bus 8 W

LED indication of the module status Got it

Short-circuit and overcurrent protection Got it

Number of channels 4

DAC resolution 16

Nominal range 4...20 A

Insulation voltage 500 V

Module consumption via 5 V bus 1 W

Module consumption via 24 V bus 8 W

LED indication of channels status Got it

LED indication of the module status Got it

Software contact bounce filtering Yes, module firmware

Maximum current consumption 0.00052 A

Short-circuit and overcurrent protection Got it

Operating atmospheric pressure 84...106.7

Dielectric strength of insulation under sinusoidal AC currents 500 V

Current on buses of potential distribution, power supply of sensors and actuators (field supply) 8 A

Power supply voltage 20.4...28.8 V

Degree of protection IP20

Maximum number of I/O modules on the CAN bus 32

Power consumption, max. 250 W

Average service life 15 a

MTBF 1000000

Relative humidity of the room, without condensation, not more than 95 %

Storage temperature range -40...70 °C

Operating temperature range -10...60 °C

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
