SNO 40-120/220-2 Strit new

LED Lighting Fixtures

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

The LED cantilever luminaire is designed for illumination of road network, adjacent territories, park and sports grounds. The body of the luminaire is made of anodised extrusion profile, own design. The design has low weight, low wind load, separate cooling zones for the LED module and driver. LED module, own design, allows you to work in a wide range of power with high efficiency without changing the design. driver of Russian production.

Specifications

Type of product according to PP RF 616 Lighting fixtures and lighting fittings other than those included in other groupings

Height 82 mm

Power consumption 40...120 W

Type by installation location Console, BCC W

Housing material Anodised aluminium housing, polypropylene end caps

Luminous flux, lm 5600...15800 lm

Upper operating temperature value 65 °C

Power supply voltage 230 V

Length 350...480 mm

Width 139 mm

Correlated color temperature 2700...6500 K

Climatic version UHL1

Type of supply current AC

Degree of protection (IP) 68

Power factor 0.85

IK code 0.8

Color rendering index (Ra) 70...80

Pulsation factor 5 %

Net weight 1.5...2.8 kg

Lower operating temperature value 40 °C

Upper operating temperature value 40 °C

Power consumption, W 40...120 W

Protection class against electric current 1

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
