Shut-off valve (valve) 1s-11-5
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Description
The shut-off valve refers to the shut-off valves of two-position action. It is used exclusively for opening or closing of pipelines by means of reciprocating movement of the shut-off organ.
- Connection to the pipeline: under welding.
- Installation position on the pipeline: any, in the upper hemisphere relative to the neck.
Designed for outdoor and indoor installation.
- Direction of medium flow: recommended under the plug.
- Gate tightness: according to class A of GOST 9544-2015.
- The valve design is adapted to the application of electric actuators: E - "ChZEM", Chekhov; EG - "GZ Elektroprivod", Moscow; ECH - JSC "ABS ZEiM Automation", Cheboksary; EN - "EZ", Cheboksary. Cheboksary; EN - "BETRO-Tech", Berdsk; EM - "Tulaelektroprivod", Tula; EC - ZPA "Resku", Czech Republic; ED - "AUMA", Germany; other manufacturers with standard connection units.
- Category of placement: 1, 2, 3 according to GOST 15150-69..
- Connection to the pipeline: under welding.
- Installation position on the pipeline: any, in the upper hemisphere relative to the neck.
Designed for outdoor and indoor installation.
- Direction of medium flow: recommended under the plug.
- Gate tightness: according to class A of GOST 9544-2015.
- The valve design is adapted to the application of electric actuators: E - "ChZEM", Chekhov; EG - "GZ Elektroprivod", Moscow; ECH - JSC "ABS ZEiM Automation", Cheboksary; EN - "EZ", Cheboksary. Cheboksary; EN - "BETRO-Tech", Berdsk; EM - "Tulaelektroprivod", Tula; EC - ZPA "Resku", Czech Republic; ED - "AUMA", Germany; other manufacturers with standard connection units.
- Category of placement: 1, 2, 3 according to GOST 15150-69..
Specifications
Material
Steel 20
Operating medium and temperature
water-vapor. tmax 425 °C
Control method
by crank or handwheel
Pressure, PN
6.3 MPa
Diameter, DN
SBVVBG mm
Climatic version
y, uxl, t according to gost 15150-69
