Shelf unit AGAT 01.05.04

Metal Shelving and Racks

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Size: 2300x400x1930. Collapsible frame is made of profile pipe 20x20x1,5mm. The frame consists of parts: 1) The connecting shelf - is a tube 20x20 length 360mm one hole at both ends diameter 10.5mm 2) The shelf "A" is installed around the perimeter of the base of the rack - tube 20x20 length 360mm with two holes at both ends diameter 10,5 and two holes under the rivet thread m6 for installation of the adjustable support 3) Strip "B" is installed in the base of the rack inside - tube 20x20 length 360mm with two holes at both ends diameter 10,5 for the set screw and two holes under the rivet thread m6 for installation of the adjustable support. 4) Aluminium brackets, adapters connecting all the slides. Brackets of 4 types are inserted inside the skid - tube 20x20 and is drawn through the threaded hole in the bracket and skid Complete with shelf 356h398h16 -12pcs, drawer 356h398h120 -4pcs, cube 356h398h358 -2pcs. Shelves, drawers and cubes made of LDFP 16mm.

Technical Specifications

Type of product according to PP RF 616	Racks, racks, metal hangers
Type of housing material	Metal
Availability of wheeled supports	no
Type of racking	straight
Frame type	metal
Number of shelves	B1/B8 2100/900 MHz pc
Rack height	1930 mm
Rack depth	400 mm
Shelf width	2300 mm
Type of installation	Stationary
Rack type	Unilateral
Frame type	metal
Coverage type	Metal powder paint
Shelf layout	Horizontal
Number of sections	1 pc

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
