Semitrailer 98131D (loading space design - load-bearing frame)

Heavy Duty Trailers

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

The trucks are designed for carriage of containers of various types, including containers and tank containers, removable tanks, removable tank bodies designed for carriage of dangerous goods. They are equipped with container locks. Technically permissible maximum weight of the vehicle is 48 tonnes. Loading space - load-bearing frame. Coupling kingpin with diameter 50.8 mm or kingpin with diameter 88.9 mm. Axles 12 tonnes manufactured by "Plant" Ltd. Tyres 11 R22,5; 12,00 R20; 295/80 R22,5; 315/80 R22,5 produced by JSC "Kordiant"/ LLC "Nizhnekamsk Tyre Plant CMK" / LLC "Nortek" / JSC "Omskshina". Wheel discs manufactured by LLC AccuRide Wheels Russia or PJSC ChKPZ. Receiver manufactured by OOO TD "AUTOTECHNOLOGIA". Lighting equipment manufactured by OOO "Atlanta". Floor level crane manufactured by VBK Vostok Ltd.

Specifications

Type of semi-trailer Container ship

Gross weight 48 t

Base machine type truck

Climatic version UHL

Type of semi-trailer Container ship

Number of axles 2 pc

Front track 1860...2068 mm

Rear track 1860...2068 mm

Axle load capacity B1/B8 2100/900 MHz t

Maximum length 16500 mm

Width 2550...3300 mm

Maximum height 4000 mm

Ergonomic parameters Paint coatings used for the exterior surfaces of semi-trailers, allow the possibility of painting or repainting them with natural drying paints; the force required to lift the spare wheel does not exceed 500 N (50 kgf). When using the mechanism

Warranty period B1/B8 2100/900 MHz

Reliability parameters Average service life before the first major overhaul under the first category of operating conditions in compliance with all operating and maintenance rules specified in the operating manual - not less than 100,000 km; MTBF under the first category of cond

Scope of application Designed for transportation of assorted and other long cargoes, with installed container locks - containers of various types, including containers and tank containers, detachable tanks, detachable tank bodies, designed for transportation of cargoes of vari

Base 3200...9500+1300..2100

Vehicle kerb weight 6000...14000 kg

Technically permissible maximum weight of the vehicle 48000 kg

Technically permissible maximum load on the coupling ball bar 23536

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
