Sectional table ("ORIGAMI") type 1, FrSt 1.6

Dimensions m/k 620h470h738.The frame is all-welded. The profile pipe 40x25x1.5 and 25x25x1.5 is used.The frame has the form of an isosceles triangle with three supports.The base of the frame - profile pipe 40x25.One of the supports - the apex of the triangle has in the base welded pipe with profile 25x25 to the base of the frame - pipe 40x25, length 200mm.The other 2 supports are the base of the triangle.In the base of the supports there are plastic supports with an inclined pin with a diameter of 49mm with the possibility of adjustment to compensate for unevenness of the floor.In the upper part of the frame from both sides in the place of the beginning of the inclined support there are rubber dampers with a diameter of 13mm through a self-tapping screw.On the other side of the frame (at the top) there are two clamps that allow fixing the table top in the working position.The table top can be raised to an angle of up to 90 degrees and fixed by a mechanism using a gaslift, which gives the tables high mobility and stackability. 6 tables are assembled in one round shape.Table top LDFP 16mm
