Available for Import

Precipitation sensor DO-04

Weather and Measurement Instruments

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

Precipitation sensor DO-04 is designed to register hydrometeors - particles of atmospheric precipitation falling in the form of rain and snow, hail, wet snow, ice rain. The sensor can be used as independent equipment, as well as to work as part of weather stations, weather stations, automated road weather stations or in systems that monitor the environment.

Specifications

Dimensions (HxWxH), mm 463x321x321

Dimensions with fixing (HxWxH), mm 550x321x321

Weight, max. 1.5 kg

Materials Aluminium alloy, stainless steel

Mounting On traverse, bracket or mast

DC source 10 ÷ 30 V, short-circuit and reverse polarity protection

Power over Ethernet (PoE) IEEE 802.3af standard

Power consumption, max. 21 W

Power consumption basic, not more 3 W

Heating power consumption, not more than 18 W

Communication interfaces Ethernet 10/100BASE-TX, RS-485

Measurement principle Optical disdrometer is a device for analysing the volumetric distribution of microparticles in a controlled medium. It allows measuring the number and size of hydrometeors flying through the optical path.

Transmitter modulation frequency 32

Service life of transmitter 20000

Additional features Control of radiation intensity; control of contamination and blocking of optical path

Precipitation intensity measurement range from 0 mm/h

Resolution of rainfall intensity 0,01 mm/h

Precipitation intensity measurement error ±(0.1 + 0.05 x Iism), where Iism is the measured value

Measuring range of precipitation amount from 0 mm

Resolution of precipitation amounts. 0.01 mm

Precipitation quantity measurement error ±(0.1 + 0.05 x Sizm), where Sizm is the measured value

Types of recorded precipitation drizzle, rain, snow, sleet, snow with rain, snow flurries, freezing rain, hail

Accumulation time 24

Ambient air temperature -50 ... +60 ?

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.

Save Your Time

Share your requirements for a quick response!

Looking for

Quantity

Your mobile

Instant response in 15 minutes

Best wholesale prices guaranteed

Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
