Power Cable with EPR Insulation RvVng(A)-LS 4x2.5

Available for Import

Power Cable with EPR Insulation RvVng(A)-LS 4x2.5 for Stationary Installation

Copper Power Cables 1kV

Manufacturer:TSVETLIT OJSC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

Power cable with EPR insulation RvVVng(A)-LS 3x25 Power cable with EPR insulation RvPng(A)-HF 3x25 Power cable with EPR insulation RvPng(A)-HF 2x2.5 Power cable with EPR insulation RvPng(A)-HF 1x6 Power cable with EPR insulation RvPng(A)-HF 1x70

Power cable with EPR insulation RvPng(A)-HF 1x95 Power cable with EPR insulation RvVVng(A)-LS 1x16 Power cable with EPR insulation RvVVng(A)-LS 1x95 Power cable with EPR insulation RvVVng(A)-LS 3x2.5 Power cable with EPR insulation RvVVng(A)-LS 1x70 Power cable with EPR insulation RvPng(A)-HF 3x10+1x6 Power cable with EPR insulation RvVVng(A)-LS 3x6 Power cable with EPR insulation RvPng(A)-HF 3x35 Power cable with EPR insulation RvVVng(A)-LS 3x10+1x6 Power cable with EPR insulation RvVVng(A)-LS 2x2.5 Power cable with EPR insulation RvVVng(A)-LS 3x35+1x16 Power cable with EPR insulation RvVVng(A)-LS 3x10 Power cable with EPR insulation RvVVng(A)-LS 3x4 Power cable with EPR insulation RvVVng(A)-LS 3x25+1x10 Power cable with EPR insulation RvVVng(A)-LS 4x10 Power cable with EPR insulation RvPng(A)-HF 2x35 Power cable with EPR insulation RvPng(A)-HF 1x25 Power cable with EPR insulation RvVVng(A)-LS 1x120 Power cable with EPR insulation RvVVng(A)-LS 4x35 Power cable with EPR insulation RvPng(A)-HF 3x25+1x16 Power cable with EPR insulation RvVVng(A)-LS 4x16 Power cable with EPR insulation RvPng(A)-HF 1x2.5 Power cable with EPR insulation RvPng(A)-HF 2x10 Power cable with EPR insulation RvPng(A)-HF 2x4 Power cable with EPR insulation RvVVng(A)-LS 2x10 Power cable with EPR insulation RvVVng(A)-LS 4x25 Power cable with EPR insulation RvPng(A)-HF 4x2.5 Power cable with EPR insulation RvPng(A)-HF 1x10 Power cable with EPR insulation RvPng(A)-HF 3x25+1x10 Power cable with EPR insulation RvPng(A)-HF 4x4 Power cable with EPR insulation RvVVng(A)-LS 3x4+1x2.5 Power cable with EPR insulation RvVVng(A)-LS 3?16+1?6 Power cable with EPR insulation RvVVng(A)-LS 4x6 Power cable with EPR insulation RvVVng(A)-LS 1x35 Power cable with EPR insulation RvPng(A)-HF 3x16+1x6 Power cable with EPR insulation RvVVng(A)-LS 1x10 Power cable with EPR insulation RvPng(A)-HF 4x6 Power cable with EPR insulation RvPng(A)-HF 1x4 Power cable with EPR insulation RvPng(A)-HF 4x16 Power cable with EPR insulation RvPng(A)-HF 4x25 Power cable with EPR insulation RvPng(A)-HF 2x25 Power cable with EPR insulation RvVVng(A)-LS 4x4 Power cable with EPR insulation RvVVng(A)-LS 3x6+1x4 Power cable with EPR insulation RvPng(A)-HF 3x16 Power cable with EPR insulation RvVVng(A)-LS 2x25 Power cable with EPR insulation RvVVng(A)-LS 1x6 Power cable with EPR insulation RvVVng(A)-LS 3x35+1x25 Power cable with EPR insulation RvPng(A)-HF 3x4 Power cable with EPR insulation RvPng(A)-HF 4x35 Power cable with EPR insulation RvPng(A)-HF 3x4+1x2.5 Power cable with EPR insulation RvPng(A)-HF 3x35+1x10 Power cable with EPR insulation RvPng(A)-HF 3x6+1x4 Power cable with EPR insulation RvPng(A)-HF 3x6 Power cable with EPR insulation RvPng(A)-HF 3x35+1x16 Power cable with EPR insulation RvVVng(A)-LS 2x4 Power cable with EPR insulation RvVVng(A)-LS 3x25+1x16 Power cable with EPR insulation RvPng(A)-HF 2x16 Power cable with EPR insulation RvVVng(A)-LS 2x6 Power cable with EPR insulation RvPng(A)-HF 2x6 Power cable with EPR insulation RvVVng(A)-LS 1x50 Power cable with EPR insulation RvVVng(A)-LS 1x25 Power cable with EPR insulation RvPng(A)-HF 1x35 Power cable with EPR insulation RvVVng(A)-LS 3?16 Power cable with EPR insulation RvVVng(A)-LS 2x35 Power cable with EPR insulation RvPng(A)-HF 1x16 Power cable with EPR insulation RvPng(A)-HF 1x50 Power cable with EPR insulation RvPng(A)-HF 3x10

Description

Cable with insulation made of ethylene-propylene rubber, sheathed in PVC-plasticate, not spreading combustion in group laying, with reduced smoke and gas emission. For fixed installation in distribution networks in hazardous areas of all classes. These cables are used for transmission of electric energy in power supply networks for industrial and civil purposes. They can be used for indoor and outdoor laying, in pipes, in cable channels, in humid environment, in underground laying. Cable insulation is resistant to moisture absorption. Cables do not spread combustion in single and group laying.

Specifications

Mark

RvVVng(A)-LS

Core material

Copper

Insulation material

ethylene propylene rubber

Sheath material

PVC plasticate of reduced fire hazard

Climatized version

?

Nominal voltage

1000 V

Ambient temperature during cable operation

-55 to +60 °C

Fire hazard class according to GOST31565

P1b.8.2.2.2.2.

Number of cores

4 pcs

Core cross section

2.5 mm²

Cable outer diameter

13.4 mm

Calculated weight

308 kg

Longest permissible operating temperature of conductors

Flat grinder, Specialised grinder °C

Twisting

insulated conductors twisted into a core

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
